Mobile Surveillance

Motorbike DVRs

VVN-MDE69

2CH / 1080P / WIFI

  • H.264

  • DC12V

  • -21~60°C

  • 110º

  • MIC Built-in

  • G-Sensor

  • 1/3CMOS

  • delayed

Download Catalog

Product Features

  • Miniature video recording system supports 2 CH 1080P video input, built-in LED indicator,
    optional for Mic.
  • H.264 compression without distortion, FHD video resolution, upgrade to H.265 compression
    saving space of storage
  • Vehicle power supply, low power consumption, good heat dissipation, no built-in lithium battery,
    no fear of high temperature, no burst doubts.
  • The device will automatically boot and then loop-record after the vehicle engine is started;
    automatically archive and then turn off after the vehicle engine is stopped.
  • The file is well formatted and saved securely with extension recording by a built-in supercapacitor.
  • USB WiFi dongle， through APP for live view /playback and video download.
  • M.I.T Novatek Soc Durable, Reliable, and clear image solution.
  • Embedded OS, vision-based driver assistance system for long operation/Record Application
  • Professional file formats to ensure completed footage without loss and to avoid SD card damage.
  • Suitable for different kinds of SD Cards, Card health status can be checked if a Vacron Smart Card is used.
SPECIFICATIONS
Record Frame 2CH 1080P@30FPS
Display Mode Dual CH Mode
Simplex Rec / Playback
Resolution Display:1920x1080 Rec:1920x1080
Backup/Record SD ; Vacron Smart Card Supported
Indication LED REC、WiFi
Video Lose Yes
SD Card Yes
G-SENSOR Yes(Option)
WIFI Yes, through APP
Systme The recording will resume once power is restored
Built-in Super Capacitor Yes
Power input input voltage DC12V
Operation Temperature -20°C∼60°C

Mic (Option)
Mic Audio Input
Indication LED 2LED (WIFI、REC)
Video Lose Yes
Dust & Water proof IP66

Camera Specification
Power Input Input Voltage DC5V ±10%
Power Comsuption 100mA
Resolution 1920(H)X1080(V)
Sensor 1/3 CMOS Sensor
View Angle H: 110° ±3
V: 65° ±3
D: 150° ±3
Temperature Range Operating Temperature：-20°∼60°
(Natural Convection Environment)
Storage Temperatue :-40°∼85°
Output termina Micro DIN
Dust & Water proof IP67
Size Ø25mm × 38mm

Download support

Software Support

　 　 　 　 　 　 　 　 　 　
Product Model DownloadExplanation
VVN-MDE69 V111__P9902023/11/28change brightness function

Download Manual

　 　 　 　 　 　 　 　 　 　
Product Model DownloadExplanation
VVN-MDE69 QUICK MANUAL V1.0
