Mobile Surveillance

Dash Cam

VVN-CBE65A

2CH / 1080P / 4G / WIFI / H.265 / Back camera compatible

  • H.265

  • 105º

  • MIC Built-in

  • G-Sensor

  • Alarm

  • USB

  • GPS

  • SD

  • Two-way

  • ADAS

  • DMS

  • GMS

  • 4G

  • WiFi

Download Catalog

Product Features

  • M.I.T Novatek Soc, Durable, Reliable and clear image solution.
  • Build-in road-facing & cabin-facing FHD camera, and support extra 1ch FHD Vacron
    camera(option)
  • Integrated 4G+GPS & WiFi module and external antenna, and support Vacron GMS Cloud
    to enable the remote management of Fleet/Vehicle with live video, location, driving condition,
    collision event/video, and the integration of customers' existing business system(optional)
  • Equipped with an ADAS camera, it can help the driver pay attention to the road ahead and
    send an alarm to remind the driver when the safety distance from the vehicle in front is too
    close or the road ahead is dangerous(option).
  • With DMS camera, it can detect whether the driver is performing fatigued or distracted driving.
    behavior and alert to lower the chances of a serious accident(option).
  • Build-in speaker & microphone to enable audio recording and IP voice communication.
  • Support programable setting on ACC-Off recording for parking mode application

System SOC

 Novatek Soc
storage device Vacron SmartInfo Micro SD card (option)
Compatible with SDXC, Class 10 or above ;
minimum support 64GB; maximum support 512GB
Lens (1) build-in Road-facing camera, up to 1080P/30fps,
FOV(D/H/V): 119°/107°/54°
(2) build-in Cabin-facing camera, up to 1080P/15fps,
FOV(D/H/V): 134°/123°/61°
Support external Vacron 3CH camera, 1080P/15fps and
5V power supply (optional)
Video function (1) Support H.265 and 1080P/720P/480P resolution on
Road-facing, Cabin-facing and external 3Ch cameras
(2) Support G-Sensor triggered event recording, file
lock and auto-upload function
(3) support ACC-OFF post-recording with software
programable timing.
(4) Support parking monitoring mode: vibration/
movement triggered event recording
Recording content Video, Sound, date/time(auto-calibrated by GPS and GMS),
G-Sensor, GPS location data
Connector I/O- mini-PCIe slot x1+Micro SD card slot x1
Standard SIM card slot x1+USB x1
Wired I/O Power cable(bare wire of Battery+Ground+ACC) x1 set
External 3ch camera-in(blue micro-DIN) x1
SMA RF external cable: 4G x1 + GPS/GNSS x1
Illumination 850nm IR LED x4 for cabin-facing camera
Buttons/LEDs/Sensors Analog microphone MIC x1, Programmable event button x1,
speaker x1, indicator LED x3 (REC+LINK+GPS)
Built-in six-axis Gyro & G-sensor
4G&GPS Support Quectel EC25 series LTE+GPS/GNSS module(optional)
WiFi USB WiFi 4 module with antenna (optional)
Support iOS/Android smartphone P2P connection and
WiFi Internet connection
Software Compliance  (1) Vacron GMS cloud platform: Support customer system
integration with events, devices, media API (on http)
and live video streaming service
(2) Vacron Cloud Protocol (VCP) can quickly connect the
dashcam to the Vacron GMS cloud with live video
streaming functions
(3) Windows version Vacron SD card player application
program
(4) SDK for Android/iOS smartphone application
development
(5) Android/iOS mobile APP: VacronLink
Accessories Mounting bracket x1, Windshield socket x1
3M double-sided tape x1
External global 4G and GPS/GNSS antenna (optional)
5/10/15m micro-DIN extension cable (optional)
Environment Operating temperature: -20℃~+55℃
Storage temperature: -40℃~+85℃
Operating humidity: 20%~80%
Storage humidity: 10%~90%
power Input  DC 12V
Regulation compliance FCC/CE
Dimension 127mm x 76.5mm x 35mm(LxWxH)
Weight 250g
