Pick Up Element
|
1/3" CMOS sensor
|
|
Video System
|
NTSC / PAL
|
|
Image Signal Process
|
Digital Signal Processor
|
|
Lens
|
2.8mm
|
|
Number Of Pixel
|
2560 (Horizontal) x1944(Vertical)
|
|
Horizontal Resolution
|
5MP@20fp/12.5fp
2MP@25fp/30fp
|
|
Power Supply
|
DC 8~28V
|
|
Power Consumption
|
120mA (IR Off)；200mA (IR On)
|
|
ICR
|
Support
|
|
Format
|
25FPS / 30FPS / PAL / NT
|
|
Audio
|
TVI support
|
|
S/N Ratio
|
≧55dB
|
|
White Balance
|
Auto
|
|
Gain Control
|
Auto
|
|
Gamma correction
|
Auto
|
|
Day Night Auto Switch
|
Support
|
|
LEDs
|
12 PCS
|
|
IR Range
|
15M
|
|
IR Wavelength
|
850nm
|
|
Minimum Illumination
|
0 Lux(IR ON)
|
|
Output
|
AHD/TVI/CVI/CVBS (Default setting: TVI Mode)
|
|
Language
|
ENGLISH/CHINESE/TRADITONAL CHINESE
|
|
Operating Temperature
|
-20℃~50℃
|
|
Dimensions (H×W×D)
|
Φ100mm x 86mm
|
|
Weight
|
About 351g
|
Simliar Product
| Update Date 2022/08/25 |
VCF-5G282HD-A |
VCF-5M282HD |
VCN-SH59282HD |
| Resolution |
5MP |
1080P |
| Pick Up Element |
1/3" CMOS |
1/2.8" CMOS |
| LENS |
3.6mm |
4mm |
| LEDS |
12 PCS |
| IR |
✓ |
| IR Wavelength |
850nm |
| IR Range |
15m |
| Sensitivity |
0.1Lux |
0.01Lux / F1.2 |
| OUTPUT |
AHD、TVI、CVI、CVBS |
| Waterproof |
IP66 |
*If the above specifications are different, please refer to the latest date
