System

Flash：16MB
RAM：DDR2 128MB*2

Image Sensor

1.3 Mega pixel 1280*1024(SXGA) 1/4” CMOS Sensor

Sensitivity

0 Lux(IR ON)

IR LED

30PCS

Lens

Board Lens 4mm F1.6 Removable IR-cut filter for day & night function

Video

H.264: 1280x1024 @25 fps

H.264: 1280x720 @30 fps

H.264: 640x480 @30 fps

H.264: 320x240 at 30 fps

Support Simultaneous multiple streams

Image Settings

Adjustable image size, quality, and bit rate

Time/Date stamp and text caption overlay.

Configurable brightness, contrast, saturation, sharpness, white balance and exposure

Format

G.711 audio encoding

Support Audio line-in for external microphone

Networking

Interface

10/100 Mbps Ethernet, RJ-45

Supported Protocol

IPv4,TCP/IP,DHCP,HTTP,RTSP,SNTP,DNS

Supported Browser

Microsoft Internet Explorer 6.0 or above
Safari, Chrome or Firefox

Alarm and Event Managemnent

Motion Detection

Event notification using SMTP or FTP

Maintenance

Supports online firmware upgrade

I/O

RJ-45 Ethernet x 1,DC Jack x 1,BNC Video out,Phone Jack Line in x 1,Alarm I/O,Reset Botton

IP Rating

 IP66

Power

DC12V or PoE IEEE802.3af Class 0

Weight

Netweight：450g

Dimension

180.6 x 80mm

Operating Environments

Temperature: 0 ~ 45 °C
Humidity: 90%
