CCTV Surveillance System

CCTV Camera

FUM-S5960H

1080P / Bullet / IP66 / Starlight Color

  • DC12V

  • 0.01 LUX

  • 50dB

  • 1/2.8"CMOS

  • -20~50°C

  • LENS 4.0mm

Download Catalog

Product Features

  • 1/2.8" CMOS sensor
  • 4.0 mm lens
  • AHD or CVBS or TVI or CVI output switch
  • IP Rating: IP66
Pick Up Element 1/2.8" CMOS sensor
Video System NTSC/PAL
Image Signal Process Digital Signal Processor
Lens 4.0mm
Number Of Pixel 1920 (Horizontal) x 1080(Vertical)
Horizontal Resolution 2M@30fps
Power Supply DC 12 ± 1V
Power Consumption 120mA
Electronic Shutter AUTO/1/50(1/60)sec ~ 1/50,000sec
White Balance Auto
Gain Control Auto
S/N Ratio ≥50dB
Minimum Illumination 0.01Lux
OUTPUT AHD / TVI / CVI / CVBS
Language English / Simplified Chinese / Traditional Chinese /German / French / Italian / Spanish /Polish / Russian/ Portuguese / Dutch / Turkish
IP Rating IP66
Operating Temperature -20℃~+50℃
Dimensions (H×W×D) 200mm x 63mm x 63mm
 Weight About 310g



Simliar Product



Update Date 2021/12/07 VCF-5M60H VCF-5560H VCN-SH5960H VCF-5760H FUM-S5960H
Resolution 5MP 1080P
Pick Up Element 1/2.8" CMOS 1/3" CMOS 1/2.8" CMOS 1/3" CMOS 1/2.8" CMOS
LENS 3.6mm 4mm
LEDS 36 PCS
IR ✓
IR Wavelength 850nm
IR Range 35M
Sensitivity 0.1 Lux 0.1 Lux 0.01 Lux 0.1 Lux 0.01 Lux
Starlight Color • •
OUTPUT AHD、TVI、CVI、CVBS
Waterproof IP66

*If the above specifications are different, please refer to the latest date
