| Video System |
Flash：16MB |
| RAM：256MB |
| Sensor |
Full HD High Quality 1/2.8” SONY CMOS Image Sensor |
| Lens |
Vari-focal 2.8~12mm F1.8 |
| IR cut |
Removable IR Cut filter |
| Low Lux |
0 Lux(IR ON) |
| IR LED |
HI-P 12pcs IR LED |
| Compression |
H.265+: 2560x1920 at 15fps |
| H.265+: 2048x1536 at 20 fps |
| H.265+: 1920x1080 at 30fps |
| H.265+、H.264、JPEG Multi-mode compression (Dual Codec) |
| Multi-mode compression streaming |
| Video Adjustment |
1.Adjustable image size, quality, and bit rate |
| 2.Time/Date stamp and text caption overlay |
| 3.Brightness, Contrast, Saturation and Sharpness |
| 4.Have: AGC、AWB、AES、BLC、WDR Features |
| Networking Interface |
10 /100 Mbps RJ-45 |
| Protocol |
IPv4, TCP/IP, DHCP, HTTP, RTSP, SNTP, DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above |
| Safari, Chrome or Firefox |
| Alarm and Event Management |
Motion Detection |
| E-mail notification or upload file to FTP |
| Users |
Max. 8 users for live view simultaneously |
| User Authorization |
| OTA |
OTA for Firmware upgrade |
| I/O |
RJ-45 , DC12V |
| Power |
DC12V |
| Power Consumption |
3.6W(IR OFF) 、18W(IR ON) |
| Weight |
N.W.：1235g |
| Dimensions |
315.5 x 147x 116 mm |
| Operating Temperature |
0 ~ 45 °C |
| IP Rating |
IP66 |
Simliar Product
| Update Date 2022/01/26 |
VIG-US730V-D6 |
VIG-US730T-D6 |
VIH-US830VC |
| Resolution |
5MP |
| Pick Up Element |
1/2.8" Sony Exmor CMOS |
1/2.8” CMOS |
| LENS |
Varifocal 2.8~12mm |
Varifocal 2.8-12mm F1.4 Varifocal 5-50mm |
| LEDS |
HI-P 12 LED |
| IR |
✓ |
| IR Range |
100M |
|
| AF |
|
✓ |
|
| Sensitivity |
0Lux |
| Waterproof |
IP66 |
| Update Date 2022/01/26 |
VIG-US730AV |
VIG-UJ730V-Z5 |
VIG-US730T-D2 |
VIH-UM230 |
| Resolution |
1080P |
720P |
| Pick Up Element |
1/2.9" CMOS |
1/3" CMOS |
1/2.8" CMOS |
1/4" CMOS |
| LENS |
Varifocal 2.8~12mm |
Auto Varifocal 2.8-12mm |
Varifocal 2.8~12mm |
| LEDS |
HI-P 12 LED |
12 pcs |
| IR |
✓ |
| IR Range |
100M |
30M |
| AF |
|
|
✓ |
|
| Sensitivity |
0Lux |
| Waterproof |
IP66 |
*If the above specifications are different, please refer to the latest date
