| Video System |
Flash：256MB |
| RAM：512MB |
| Sensor |
SONY FullHD High Quality 1/2.8” CMOS Image Sensor |
| Lens |
Auto Varifocal 2.8-12mm |
| IR cut |
Removable IR-cut filter for day & night function |
| Low Lux |
0.01 Lux |
| IR LED |
HI-P 12 IR LED |
| Compression |
H.265/H.264: 2592x1944 at 30 fps |
| H.265/H.264: 2560x1440 at 60 fps |
| H.265/H.264: 2048x1536 at 60 fps |
| H.265/H2.64: 1920x1080 at 60 fps |
| H.265、H.264 Multi-mode compression (Dual Codec) |
| Support Simultaneous multiple streams |
| Image Settings |
1.Adjustable image size, quality, and bit rate |
| 2.Time/Date stamp and text caption overlay |
3.Configurable brightness, contrast, saturation, sharpness
white balance and exposure
|
| 4.Have: AGC、AWB、AES、BLC、WDR Features |
Electronic Shutter
|
1/2 ~ 1/100,000 Sec |
| Networking Interface |
10 /100 Mbps RJ-45 |
| Protocol |
IPv4, TCP/IP, DHCP, HTTP, RTSP, SNTP, DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above |
| Safari, Chrome or Firefox |
| Alarm and Event Management |
Motion Detection |
| Event notification using SMTP or FTP |
| Users |
Clients on-line monitoring at the same time |
| Multi-level user access control with password protection |
| Maintenance |
Supports online firmware upgrade |
| I/O |
RJ-45 Ethernet x 1,DC12V |
| Power |
DC12V |
| Max. Power Consumption |
3.6W(IR OFF) 、10W(IR ON) |
| Weight |
N.W.：650g |
| Dimensions |
255mm x 75.3mm x 75mm |
| Operating Temperature |
0 ~ 45 °C |
| IP Rating |
IP66 |
