CCTV Camera
Product Features
|
Image Sensor |
1/2.8" CMOS Image Sensor |
|
Signal Mode |
NTSC / PAL |
|
Image signal processing system |
Image signal processing system |
|
Lens |
1.8mm |
|
Effective Pixel |
1920(Horizontal) x 1080(Vertical) |
|
Resolution |
1080P@30fp |
|
Power |
DC 12 ± 1V |
|
Power Consumption |
120mA |
|
ICR |
Support |
|
Electronic Shutter |
AUTO/1/50(1/60)sec ~ 1/50,000sec |
|
White Balance |
Auto |
|
Auto Gain |
Auto |
|
S/N Ratio |
≥50dB |
|
Minimum Illumination |
0.01 Lux |
|
Output |
AHD or CVBS (Factory Preset: AHD) |
|
Language |
English, Simplified Chinese, Traditional Chinese, |
|
Operating Temperature |
-20℃~50℃ |
|
Dimensions (H×W×D) |
46.7mm x 51mm x 25.5mm |
|
Weight |
Apx. 90 g |
Simliar Product
| Update Date 2021/12/07 | VCF-5K37H | VCN-S5937H | VCN-SH5937H | VCF-5537H | VCF-5737H |
| Resolution | 5MP | 1080P | 1080P | 1080P | 1080P |
| Pick Up Element | 1/2.5" CMOS | 1/2.8" CMOS | 1/2.8" CMOS | 1/3" CMOS | 1/3" CMOS |
| LENS | 3.6mm | ||||
| LEDS | 8 PCS | ||||
| IR | ✓ | ||||
| IR Wavelength | 850nm | ||||
| IR Range | 35m | 30m | 30m | 35m | 35m |
| Sensitivity | 0.2Lux | 0.01Lux | 0.01Lux | 0.1Lux | 0.1Lux |
| Starlight Color | • | ||||
| OUTPUT | AHD、CVBS、TVI、CVI | ||||
| Waterproof | IP66 | ||||
*If the above specifications are different, please refer to the latest date
