Terms
|
Specifications
|
|
Sensor
|
Front 1080P CMOS Sensor
Rear 720P CMOS Sensor
|
|
Camera view angle
|
Front camera view angle approx.120°
Rear camera view angle approx. 130°
|
|
Voltage
|
-
Require 5V±5%, 1A Cigarette lighter adapter. Start voltage as 4.7v above.
-
Built-in1.5Fsupercapacity as backup power for file storage.
|
|
Operating Temp
|
-15℃~+65℃
|
|
Storage device
|
Recommend using Class 10 above micro-SDHC Card (8G above) MAX TO 128GB.
|
|
Recording Frame
|
Front 1920x1080 Max. Fps as 25/25Fps (NTSC/PAL)
Rear 1280x720 Max. Fps as 15/15fps (NTSC/PAL)
Auto record when power up system; backward facing lens can be closed by setting of software.
|
|
Recording contents
|
Date, time, image, sound, G-sensor data, GPS data.
|
|
Storage format
|
-
Specific format for software player.
-
H.264 compression
|
|
Microphone
|
Build-in high sensitivity of single microphone for automatic voice adjustment
|
|
Time setting
|
GPS auto adjustment, use built in calendar clock if no GPS signal.
|
|
G-Sensor
|
Internal 3D G-Sensor
|
|
GPS
|
Built-in GPS, capable connect with G-MOUSE.
GPS position, drive route tracking record.
|
|
WIFI
|
Built-in USB WIFI Dongle(2.4G HZ)。
|
|
Output/input device
|
-
VIDEO OUT: TV-Out (1 Vp-p composite video output, 75 ohms)
-
Video Output format: NTSC / PAL alternative.
-
Force Record Button: For emergency recording. Gleams in night time.
-
Red light: Recording indicator. In emergency recording, it flashes more frequently.
-
Green light: GPS connecting light (Flashing light means that 3D positioning is not ready, bright means that 3D already positioning).
-
Blue light: WiFi connection light (flash light means WiFi do not connect, bright means success connect with WiFi.
-
EXT: extra GPS Mouse external jack. Note: under night mode, the infrared ray is on and the indicator light is dimmed.
|
