Video System
|
NTSC
|
PAL
|
|
Pick Up Element
|
SONY IMX335 1/2.8” Inch CMOS Image Sensor
|
|
Image Signal Process
|
Digital Signal Processor
|
|
Lens
|
2.9mm
|
|
Number Of Pixel
|
2688 (Horizontal) x 1512(Vertical)
|
|
Picture Elements
|
4.0 Mega Pixel
|
|
Horizontal Resolution
|
Color: 4MP/30fps
|
Color: 4MP/25fps
|
|
Power Supply
|
DC 5 ± 0.5V ( 180 mA)
|
|
Power Consumption
|
0.9W
|
|
Synchronization
|
INTERNAL
|
|
Scanning System
|
2 : 1 Interlace
|
|
Minimum Illumination
|
0.1 LUX
|
|
S/N Ratio
|
Max 50 dB
|
|
Auto Gain Control
|
AUTO
|
|
White Balance
|
AUTO
|
|
Electronic Shutter
|
Auto: 1/30NTSC(1/25 PAL)s TO 1/50,000s
|
|
Output
|
1 Vp-p Composite Video Output, 75 Ohms
|
|
View Angle
|
H:110°
|
|
Operating Temperature
|
- 10° C ~ + 60°C
|
|
Dimensions ( H × L )
|
42.5 x 60 x 53mm
|
|
Waterproof
|
IP66
|
|
Weight
|
82g
|
|
Simliar Product
| Update Date 2022/01/25 |
AVM-S525D |
AVM-S225C |
AVM-S225B |
AVM-H225A |
AVM-H225B |
| Resolution |
1080P |
1080P |
720P |
1080P |
960H |
| Pick Up Element |
SONY IMX335 1/2.8” Inch CMOS |
1/2.9" SONY CMOS |
1/2.9" SONY CMOS |
1/4”CMOS |
1/4”CMOS |
| Lens |
2.9mm |
3.6mm&2.8mm |
2.6mm |
2.0mm |
2.0mm |
| Sensitivity |
0.1 lux |
| View Angle |
H:(90˚&110˚) |
H: 80° |
| Waterproof |
IP66 |
*If the above specifications are different, please refer to the latest date
