| Ssystem |
Flash：16MB |
| RAM：256MB |
| Image Sensor |
Full HD High Quality 1/2.8” SONY CMOS Image Sensor |
| Lens |
Vari-focal 2.8~12mm F1.8 |
| IR-cut |
Removable IR Cut filter |
| Low Lux |
0 Lux(IR ON) |
| IR LED |
HI-P 8 LED |
| Compression |
H.265+: 2560x1920 at 15fps |
| H.265+: 2048x1536 at 20 fps |
| H.265+: 1920x1080 at 30fps |
| H.265+、H.264、JPEG Multi-mode compression (Dual Codec) |
| Multi-mode compression streaming |
| Image Settings |
Resolution、Quality and bit rate |
| Time、Date or custom text and it’s position |
| Brightness, Contrast, Saturation and Sharpness |
| AGC、AWB、AES、BLC、WDR |
| Electronic Shutter |
1/2 ~ 1/100,000 Sec |
| Network Interface |
10 /100 Mbps RJ-45 |
| Protocol |
IPv4,TCP/IP, DHCP, HTTP, RTSP,SNTP,DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above |
| Safari, Chrome or Firefox |
| Alarm & Event notification |
Motion Detection |
| E-mail notification or upload file to FTP |
| User |
Max. 8 users for live view simultaneously |
| User Authorization |
| OTA |
OTA for Firmware upgrade |
| I/O Port |
RJ-45, DC12V |
| Power |
DC12V or PoE IEEE802.3af Class 0 (optional) |
| Power Consumption |
3.6W(IR OFF) 、18W(IR ON) |
| Weight |
N.W.：965g |
| Dimension |
315x88x87 mm |
| Operating Environments |
0 ~ 45 °C |
| IP Rating |
IP67 |
Simliar Product
| Update Date 2022/01/26 |
VIG-US731V-D6 |
VIG-US731AV |
VIG-US731T-D2 |
VIG-UJ731V-Z5 |
| Resolution |
5MP |
1080P |
| Pick Up Element |
1/2.8" Sony Exmor CMOS |
1/2.9" CMOS |
1/2.8” SONY CMOS |
1/3" CMOS |
| Lens |
Varifocal 2.8~12mm |
Auto Varifocal 2.8-12mm f1.4 |
Varifocal 2.8~12mm |
| LEDS |
8 HI-P LEDS |
| IR |
✓ |
| IR Range |
30M |
| AF |
|
✓ |
|
| Sensitivity |
0 LUX |
| Waterproof |
IP66 |
| Update Date 2022/01/26 |
VIH-US831VM |
VIH-US831VF |
VIH-UH831 |
| Resolution |
1080P |
1.3MP |
| Pick Up Element |
1/2.8" CMOS |
1/2.8" CMOS |
1/4" CMOS |
| Lens |
Varifocal 2.8~12mm |
| LEDS |
8 HI-P LEDS |
| IR |
✓ |
| IR Range |
30M |
| Sensitivity |
0 LUX |
| Waterproof |
IP66 |
*If the above specifications are different, please refer to the latest date
