CCTV Camera
5MP / dome / IR
DC12V
LENS 3.6mm
30M
50dB
8 LEDs
0.2 LUX
-20~85°C
CMOS 1/2.5"
Product Features
Pick Up Element | 1/2.5" CMOS sensor |
Video System | NTSC/PAL |
Image Signal Process | Digital Signal Processor |
Lens | 3.6mm |
Number Of Pixel | 2608 (Horizontal) x 1952(Vertical) |
Horizontal Resolution | 5MP@20fps |
Power Supply | DC 12 ± 1V |
Power Consumption | 120mA(IR Off);340mA(IR On) |
ICR | Support |
Electronic Shutter | Auto |
White Balance | Auto |
Gain Control | Auto |
S/N Ratio | ≥50dB |
Day Night Auto Switch | Support |
LEDs | 8 PCS |
IR Range | 30M |
IR Wavelength | 850nm |
Minimum Illumination | 0.2Lux |
OUTPUT | AHD or CVBS or TVI or CVI (Default setting: AHD Mode) |
Language | English / Simplified Chinese / Traditional Chinese / Russian / Spanish / French / Polish / Italian / Portuguese / Japanese / Korean / Greek |
Operating Temperature | -20℃~+85℃ |
Dimensions (H×W×D) | Φ99 × 72 mm |
Weight | About 185g |
Simliar Product
Update Date 2022/02/11 | VCF-5M16HDB | VCN-S5916HDB | VCF-5716HDB | VCF-5K16HDB |
Resolution | 5MP | 1080P | 1080P | 5MP |
Pick Up Element | 1/2.8" CMOS | 1/2.8" CMOS | 1/3" CMOS | 1/2.5" CMOS |
LENS | 3.6mm | |||
LEDS | 8 PCS | |||
IR | ✓ | |||
IR Wavelength | 850nm | |||
IR Range | 30m | |||
Sensitivity | 0.1Lux | 0.01Lux | 0.1Lux | 0.2Lux |
OUTPUT | AHD、CVBS、TVI、CVI |
*If the above specifications are different, please refer to the latest date
Download support
Download Manual
Product Model | Download | Explanation |
VCF-5K16HDB | V.01 |
